Sustainable Packaging Specification Recommendations for Automotive Manufacturing Operations
The Suppliers Partnership for the Environment (SP) – an association of global automakers and their suppliers working together to advance environmental sustainability through the automotive supply chain – has published the latest version of its guidance document, Sustainable Packaging Specification Recommendations for Automotive Manufacturing Operations (Version 2.0, 2022).
The guidance document was produced through a collaborative process by the Suppliers Partnership for the Environment (SP) Sustainable Materials Work Group Sustainable Packaging Sub-Team, whose members include automotive original equipment manufacturers such as Ford Motor Company, General Motors, Honda Development & Manufacturing America, Stellantis, Toyota Motor North America, and their suppliers.
The purpose of this guidance document is to provide straightforward industry-supported guidance to help automakers and their suppliers source sustainable packaging designs for use in automotive manufacturing operations.
Sustainable Packaging Specification Recommendations for Automotive Manufacturing Operations
A succinct set of practical recommendations to help automotive original equipment manufacturers (OEMs) and suppliers source sustainable packaging designs for use in automotive manufacturing operations. These recommendations focus on opportunities to minimize automotive packaging waste and address barriers to recyclability in the design phase.
Recyclability of Common Automotive Packaging Materials in U.S.
The guidance document includes information on the viable recyclability of common packaging materials / designs used in the automotive industry in the United States. This information is intended to help support consideration of opportunities to minimize automotive packaging waste and address barriers to recyclability in the design phase, where possible.
Packaging Material / Design Type | Viable Recyclability Classification | Class A Protection | Reference in SP Packaging Guidance |
---|---|---|---|
Cross-linked polyethylene (XLPE) |
![]() |
![]() |
SP II.3 |
Extruded polyethylene (PE) |
![]() |
SP II.3 | |
Expanded polyethylene (EPE) |
![]() |
![]() |
SP II.3 |
Molded expanded polypropylene (EPP) |
![]() |
![]() |
SP II.5 |
Cut plank expanded polypropylene (EPP) |
![]() |
SP II.5 | |
Expanded polystyrene (EPS) |
![]() |
SP II.3 | |
Polyurethane foam (PU) |
![]() |
SP II.3 | |
Expanding polyurethane foam formed within plastic bags |
![]() |
SP II.4 | |
Air-filled paper |
![]() |
SP II.4 | |
One-sided synthetic flash spun high density polyethylene fiber coating |
![]() |
![]() |
SP II.6 |
Two-sided synthetic flash spun high density polyethylene fiber coating |
![]() |
![]() |
SP II.6 |
Brushed nylon |
![]() |
![]() |
SP II.6 |
Corrugated board /old corrugated container (OCC) boxes attached to wood pallets with screw fasteners, nails or staples |
![]() |
SP II.7 | |
Corrugated board /old corrugated container (OCC) boxes attached to wood pallets with plastic banding |
![]() |
SP II.7 | |
Metal clips on plastic banding |
![]() |
SP II.8 | |
Metal bandings |
![]() |
SP II.8 | |
Corrugated board/OCC boxes reinforced with metal brackets and/or wood |
![]() |
SP II.9 | |
Corrugated board/OCC boxes reinforced with cardboard brackets and / or spacers |
![]() |
SP II.9 | |
Single-use tape (plastic with adhesive) |
![]() |
SP II.10 | |
Dunnage with laminates, vinyl labels, PVC components, glues, foam, and/or wire |
![]() |
SP II.11 | |
Low density polyethylene (LDPE) / Linear low-density polyethylene (LLDPE) |
![]() |
SP II.12 | |
Polypropylene and polyester fabric bags |
![]() |
![]() |
SP II.13 |
Wood pallets |
![]() |
SP II.15 | |
Oriented strand board (OSB) |
![]() |
SP II.16 | |
Polypropylene and polyethylene sleeve packs |
![]() |
SP II.16 | |
Triple wall corrugated board sleeve packs |
![]() |
SP II.16 | |
Wooden crates assembled with large steel bolts / plates |
![]() |
SP II.17 | |
Wooden crates assembled with removable clips |
![]() |
SP II.17 | |
Dunnage secured with hook-and-loop fasteners, glue and/or double-sided tape |
![]() |
SP II.18 | |
High Density Polyethylene (HDPE) Totes |
![]() |
SP II.11 | |
Polypropylene corrugated plastic sheet |
![]() |
SP II.11 | |
HDPE corrugated plastic sheet |
![]() |
SP II.11 | |
Corrugated plastic with PU Foam attached |
![]() |
SP II.6 | |
Corrugated plastic insert with Fabric |
![]() |
SP II.6 | |
Corrugated plastic covered with fabric |
![]() |
SP II.6 |
Key Definitions
- Viably Recycled. For the purposes of this guidance, a material is considered to be viably recycled where established systems are in place with capability to technically, and economically, recycle the material in major automotive operating regions in the United States. To be considered economically sustainable, the material must have a market value that typically meets or exceeds the cost to collect, transport and process the material for recycling. Consideration of materials that can be processed into resin for use back into the same or similar application is typically preferred where possible, however materials that are downcycled for use in other industries may be suitable where economically sustainable recycling systems exist.
- Detrimental to Recycling. For the purposes of this guidance, packaging materials or designs that require separation or other pre-processing in order to be acceptable into established recycling systems are considered to be detrimental. While the challenges presented by these materials can often technically be overcome, the additional time, labor and other costs required to do so may outweigh the recycling value thereby increasingly the likelihood that the material may be sent to landfill.
Please reference the full guidance document for more information on the materials referenced above.
Acknowledgements: This guidance document was produced through a collaborative process by the Suppliers Partnership for the Environment (SP) Sustainable Materials Work Group Sustainable Packaging Sub-Team. The 2022 version included input and review from representatives of Action Wood 360, AI Trading, ARPLANK Direct, Avangard Innovative, DENSO, Doug Brown Packaging Products, Ford Motor Company, General Motors, Green Processing Company, Honda Development & Manufacturing America, JSP, Lear Corp, Magna International, Mustang Innovation, Primex Design & Fabrication, Real Quality Services, Stellantis, Toyota Motor North America, Toyota Tsusho America, and UGN. The 2022 project was co-chaired by: Bridget Grewal, Magna International; and, Matt Marshall, Toyota Motor North America.
Disclaimer: This document is intended to provide information for automakers, their suppliers and the general public on sourcing sustainable packaging designs. The information included in this document is based on the professional judgment of the individual authors and reviewers and may be used at a company’s discretion. SP and its member companies make no warranty, expressed or implied, and assume no liability for any form of damage that may result from the application of the information contained in this document.
Contact: Please submit any feedback on this guidance or suggestions for future improvements to info@supplierspartnership.org.
